Product Details
| Material |
Applicable Devices |
| Woven |
Paste Extrusion Equipment |
| Non Woven |
Powder Filling Equipment |
| Type |
Battery Gauntlet/ PT bag |
| Application |
Traction battery, stationary battery, EV battery |
| Material |
textile |
| Color |
yellow, white |
| ER |
<=0.0035 |
| Porosity |
>=58 |
Polyester/Woven Gauntlet Production Process
- Weave polyester yarn into fabric.
- Dip the polyester fabric in glue and dry it.
- Form the manifold with a tube drawing machine.
- Cut to required dimensions per customer request.
Product Strength
Our gauntlet adopts the advanced textile and curing technology with 1 million square meters production capability.
The terylene gauntlet has advantages: lower electrical resistance, higher porosity, higher mechanical strength, higher anti oxidation, higher stability and elastic control.
It is widely used in traction battery, stationary battery and EV battery, it can meet the requirements for the oxide filling and paste filling processes.
| ER |
<= 0.0035 |
| Porosity % |
>=58 |
| Tensile strength(N/cm) |
>=390 |
| Detoration under force(N) |
>=36 |
| Acid resistance |
>=0.7 |
| Content of CI |
<=0.003 |
| Reductive KMnO4 |
<=12 |
| Weight loss after soaking in acid |
<=1.50-0.30 |
About Us
LAKER AUTO PARTS CO., LIMITED is your one-stop shop for parts and accessories for forklifts, low-speed electric vehicles, and auxiliary material handling equipment. We guarantee high-performance products at competitive prices.
Our Core Products Include:
- Lead Acid Batteries for electric forklifts and vehicles.
- Intelligent automatic battery chargers (industrial frequency and high frequency).
- Solid tires (regular black and non-marking) for small working fields and warehouses.
- Hydraulic solid tire press machines for tire mounting and dismounting.
- Mobile loading ramps and fixed dock levelers for container loading.
- Low-speed electric vehicles (1-3 tons) for warehouse, airport, and port delivery.
- A variety of battery accessories (battery plates, gauntlets, connectors, watering systems, safety valves, vent plugs, cables, etc.).
- Various golf carts and sightseeing vehicles.
At LAKER, we are committed to providing comprehensive service from the initial quote to final delivery. Our dedication to quality, expertise, and product availability has made us a trusted partner for our customers.
All forklift-related products are sourced from top manufacturers under our brands MYING and LAKER. Our skilled technicians are always available for online technical support and aftermarket solutions.
Join Us in Powering the Future!
We strive to enrich our catalog with environmentally friendly maintenance products for material handling equipment. Given the opportunity, we are eager to demonstrate our advantages and grow together, establishing a long-term and friendly business relationship with your esteemed company.
Power Your Lift, Lift Our Future—You Can Depend On Us!
